Woven Roving



Woven roving is made of roving drawn from big bushings. It is mainly used in hand and

machine production. The typical products include boats, storage tanks, large sheets

and panels, furniture, etc.



Product Characteristics:

1. Even thickness, no fuzz, no stain.

2. Fast wet-out, products with high strength, little loss for strength in damp

situation.



Product Parameter:



200g,400g,500g,600g,800g woven roving is available

Product code	EWR500-100	EWR600-100	EWR800-100	CWR900-100
Unit weight(g/m2)	500±20	600±20	800±20	900±20
Width (mm)	1000±10	1000±10	1000±10	1000±10
Length (m)	100±4	100±4	100±4	100±4

Multi-Axial fabric

Multi-axial fabrics is non-crimp, multi-axis and multi-layered reinforcements. Layer count, orientation, weight and fiber content of the layers vary based on product line and application. The layers are stitched via polyester yarn. Fabrics can be produced using multiple axis(0°,90 °,+45°,-45°),or combined with chopped mat and multiple layers of veil and/or non-woven materials. The typical application of this kind of products are wind energy, marine/ship building, recreation/leisure products, automotive, aerospace & defense etc.

Properties：

• Increased strength, reduced product weight and better surface finish.
• Orientated unidirectional layers are structurally more efficient
• Quicker to wet-out than woven fabrics
• Available in very heavy weights allowing faster deposition rates
• Binderless CSM can be added to further cut down on lay-up time and increase speed of wet-out

Packaging

Woven Roving is winded by a paper tube with an inside diameter of 80mm, and the roll is wrapped up with the plastic film, and then packed into a carton.It can be loaded into a container directly by carton or on pallets.

Carton Package

Pallet length (mm)	1140	1140
Pallet width (mm)	1140	1140
Pallet height (mm)	955	1220











Pallet Package

Package length	240mm
Package width	240mm
Package height(mm)	Width + 50mm



Storage

Woven roving should be stored in its original packaging in a dry and cool place. Best conditions are at temperatures from 15 to 35°C and humidity between 35 and 65%.
